Tough bellows
Impact force is adjustable with variable jumping stroke that can be set by throtte control
Easy to use, fuel-efficient, low price.
Tough bellows
Impact force is adjustable with variable jumping stroke that can be set by throtte control
Easy to use, fuel-efficient, low price.
Double-cleaner(main cleaner and pre-cleaner=four filtrtion),and it reduces maintenance at main cleaner.
Outstanding body balance maximizes work efficiency and minimizes operator's fatigue.
Ergonomic, streamlines,eye appealing design, Meticulous attention to safety and operators.
Fewer frequent maintenance cycles in routine operation.
|
Model |
ZDCR70A |
ZDCR70 |
ZDCR70B |
|
Impact frequency (Number/min) |
700 |
700 |
700 |
|
Jump height (mm) |
65 |
65 |
70 |
|
Power (kw/r/min) |
2.2/4000 |
2.2/4000 |
2.6/3600 |
|
Net weight (kg) |
75 |
75 |
80 |
|
Box size (mm) |
1080×410×750 |
1080×410×750 |
1080×410×750 |
|
Supporting power |
HONDA GX100 |
156FC |
Robin EH-120 |
|
Impact energy (Kn) |
15 |
15 |
16 |
|
Walking speed (m/min) |
17 |
17 |
17 |
|
Seesaw size (mm) |
280×335 |
280×335 |
280×335 |
|
Gross weight (Kg) |
92 |
92 |
100 |
