Bucket Capacity(m3): 0.023
Swing Speed(rmp): 0-13
Gradeablity(°): 30
1. High quality hydraulic parts ensure the stable quality.
2. Special design on separating engine and radiation space, using enhanced cooling fan to increase cooling efficiency
3. Famous Yuchi Engine, high efficiency, low repair cost.
4. equipped with double fuel filter to guarantee fuel purity to protect engine
5. extend hydraulic line for various attachments.
| Specifications | |
| Bucket Capacity(m³) | 0.023 |
| Swing Speed(rmp) | 0-13 |
| Gradeablity(°) | 30 |
| Max.Bucket Digging Force(KN) | 7.2 |
| Max.Arm Digging Force(KN) | 4.6 |
| Engine Model | KD192F—1 |
| Power/revolution speed(KW/rmp) | 7/3000 |
| System Pressure(MPa) | 16 |
| Machine size | |
| Dimension Length*Width*Height(mm) | 2840x880x2220 |
| Cabin Height(mm) | 2220 |
| Axle Base | 900 |
| Wheel(track) Distance(mm) | 660 |
| Minimum ground clearance(mm) | 132 |
| Tail Swing Radius(mm) | 800 |
| Working range | |
| Max.Digging Height(mm) | 2600 |
| Max.Dumping Height(mm) | 1830 |
| Max.Digging Depth(mm) | 1715 |
| Max.Vertical Digging Depth(mm) | 15901 |
| Max.Digging Radius(mm) | 3065 |
| Min.Swing Radius(mm) | 1480 |
21200kg
133KW 2000rmp
44900kg
250KW 2000rmp
49600kg
280KW 2000rmp
56000kg
298KW 1800rmp
