Swing Speed: 11-13RMP
Bucket capacity : 1.1m³
Engine power: 133KW/2000RMP
| Description | Unit-Metric | Unit-US |
| Overall length | 8540mm | 336.2in |
| Overall width | 2720mm | 107.1in |
| Overall height | 2920mm | 115in |
| Cabin height | 2920mm | 115in |
| Track length on ground | 3200mm | 126in |
| Track gauge | 2120mm | 83.5in |
| Min.ground clearance | 480mm | 18.9in |
| Swing radius at tail | 2430mm | 95.7in |
| Max.digging height | 9430mm | 367in |
| Max.dumping height | 6960mm | 274in |
| Max.digging depth | 5975mm | 235.2in |
| Max.vertical digging depth | 5630mm | 221.7in |
| Max.digging radius | 8985mm | 353.7in |
| Min.swing radius | 2725mm | 107.3in |
| Bucket capacity | 0.8m³ |
| swing speed | 0~12rpm |
| Max.gradeability | 30° |
| Max.digging force of grab | 98KN |
| Max.digging force of arm | 68KN |
| Engine model/power | YUCHAI YC4A140, 103kw/2200r/min |
| CUMMINS QSF3.8, 93kw/2200rpm | |
| Tack width | 600mm |
| System pressure | 32Mpa |
