MC380J Hydraulic Crawler Excavator

Swing Speed : 0-11rmp

Bucket Capacity : 1.7 m³

Power/revolution speed : 219KW/1900rmp

Get a quote for free Product manual download

Technical characteristicsPerformance ParameterRelated ProductsContact Us

Technical characteristics
  • Large Excavator Mining Excavator MATCH MC380J 37Ton 38Ton 40Ton 38Ton 40Ton Crawler Excavator
  • MATCH Excavator MC380J excavator is a crawler-type machine designed for heavy-duty operations.
  • The MATCH MC380J large crawler excavator combines exceptional performance, high reliability, and user-friendly design. It
  • excels in multiple core configurations and technologies, delivering exceptional operating efficiency and durability.
  • Equipped with a high-power engine from a renowned brand, it delivers ample power to meet the demands of high-intensity operations.
  • The system's precise matching and optimized energy-saving controls significantly reduce fuel consumption.
Performance Parameter
Specifications
Bucket Capacity(m3) 1.7
Swing Speed(rmp) 0-11
Gradeablity(°) 35
Max.Bucket Digging Force(KN) 244
Max.Arm Digging Force(KN) 200
Engine Model SL9
Power/revolution speed(KW/rmp) 219/1900
Tire Model —
System Pressure(MPa) 35
Machine size
Dimension Length*Width*Height(mm) 11285x3190x3664
Cabin Height(mm) 3168
Axle Base(mm) 4099
Wheel(track) Distance(mm) 2590
Minimum ground clearance(mm) 536
Tail Swing Radius(mm) 3590
Working range
Max.Digging Height(mm) 10511
Max.Dumping Height(mm) 7572
Max.Digging Depth(mm) 7372
Max.Vertical Digging Depth(mm) 6731
Max.Digging Radius(mm) 11178
Min.Swing Radius(mm) 3865
