Machine weight: 6800kg
Rated displacement : 2.982L
Power Output: 55KW/2200r/min
The MC80W wheeled excavator is a versatile machine that combines power, efficiency, and energy conservation. Its powerful 48kW Yuchai engine provides continuous and stable energy output, enabling it to easily handle complex working conditions. It also excels in fuel efficiency, significantly reducing fuel consumption and lowering operating costs.
Main configuration:
1. Yuchai 55kW engine
2. Weifu main pump, Husk main valve
3. Liansheng 8-ton heavy-duty axle, hydraulic travel, with bulldozer, crushing pipeline, and air conditioning
|
OVERALL DIMENSIONS |
||||
|
A |
Total length |
6000 mm |
||
|
B |
Total height |
2 8 4 0 mm |
||
|
C |
Overall width |
2 040 mm |
||
|
D |
Cab end |
2 8 4 0mm |
||
|
E |
Wheelbase |
1 70 0mm |
||
|
F |
Wheelbase |
23 8 0mm |
||
|
G |
boom |
340 0mm |
||
|
H |
Stick |
185 0mm |
||
|
Scope of work |
||||
|
A |
Maximum digging height |
6980 mm |
||
|
B |
Maximum unloading height |
5100 mm |
||
|
C |
Maximum digging depth |
3360 mm |
||
|
D |
Maximum vertical digging depth |
2890mm |
||
|
E |
Maximum digging radius |
6510 mm |
||
|
F |
Maximum surface excavation radius |
6330mm |
||
|
G |
Minimum turning radius of front end |
2265 mm |
||
|
H |
Minimum turning radius at rear end |
1880 mm |
||
|
Technical Parameters |
||||
|
Machine weight |
6.8 T ±5% |
|||
|
Engine Model |
YC4FA75Z-T21 |
|||
|
Type |
Four-cylinder water-cooled |
|||
|
Rated displacement |
2.982L |
|||
|
Power Output |
55KW / 2200r /min |
|||
|
Walking speed |
0-30 km/h |
|||
|
Gradeability |
2 0 ° |
|||
|
Minimum ground clearance |
250 mm |
|||
|
Main pump type |
variable displacement axial piston pump |
|||
|
Maximum flow |
158 L/min |
|||
|
Rotation speed |
10 r/min |
|||
|
Bucket Capacity |
0.25m³ |
|||
