RATED POWER: 75KW
OPERATING WEIGHT: 9300-10300kg
ENGINE: YUCHAI /CUMMINS
| Model | MC886T | MC886H | |
| Transport Dimension | |||
| Overall Operating Weight | 8200-9300kg | 9300-10300kg | |
| L*W*H | 6150×2250×3763mm | 6450x2530x3940mm | |
| Wheel base | 2280mm | 2335mm | |
| Min. Ground Clearance | 300mm | ||
| Performance | |||
| Bucket Capacity | 1.0m³ | 1.2m³ | |
| Breakout Force | 47KN | ||
| Loading Lifting Capacity | 2500KG | ||
| Bucket Dumping Height | 2760mm | 3050mm | |
| Bucket Dumping Distance | 900mm | 870mm | |
| Digging Depth | 52mm | ||
| Backhoe Capacity | 0.3m3 | ||
| Bucket digging force | 50KN | ||
| Max. Digging Depth | 4082-5100mm(Telescopic arm) | 3820-4970mm(Telescopic arm)聽 | |
| Swing Angle of Excavator Grab | 180o | ||
| Max. Pulling Force | 60KN | 86KN | |
| Front loading hydraulic pressure | 19Mpa | 20Mpa | |
| Rear excavating hydraulic pressure | 19Mpa | 20Mpa | |
| Engine | YUCHAI /CUMMINS | ||
| Model | YC4A105Z-T20/4BTA3.9-C100 | ||
| Type | In Line Direct injection Four-Stroke and Injection Combustion Chamber | ||
| Cylinder-Inside Diameter*Stroke | 4-108×132mm | 4-102×120mm | |
| Rated Power | 75KW | 74KW | |
| Rated Speed | 2200r/min | 2200r/min | |
| Min. Fuel Consumption | ≤230g/km.h | ≤223g/km.h | |
| Max.Torque | ≥400N.M/1500r/min | ≥410N.M/1500r/min | |
| Displacement | 4.8L | 3.9L | |
| Steering System | |||
| Model of Steering Device | BZZ5-250 | ||
| Steering Angle | ±36 o | ||
| Min. turning radius | 6581mm | 6950mm | |
| Pressure of the system | 14Mpa | ||
| Max. load of Front Axle | 22.5 ton | 13 ton | |
| Max. load of rear Axle | 18.5 ton | 13 ton | |
| Main Transmission | |||
| Type | Mechanically operated Hydraulic synchronized shift | ||
| Gears | 2F2R | 4F4R | |
| Max.Speed | 22Km/h | 36Km/h | |
| Hydraulic torque converter | YJ280 | YJ315 | |
| Cooling type | Oil cooling pressure circulation | ||
| Pump flow | 40mL/r | ||
| Tyre | |||
| Model | 14-17.5/19.5L-24 | 16.9-28 | |
| Pressure of Front wheel | 0.4Mpa | 0.35 Mpa | |
| Pressure of Back Wheel | 0.35 Mpa | 0.35 Mpa | |
| Brake System | |||
| Service Brake | Air Over Oil Caliper Brake External Type Self-regulation Self-balance | ||
| Paking Brake | Manual brake | ||
