RATED POWER: 132kw/min
BUCKET CAPACITY: 2.35m³
lifting time: ≤5.5s
The wheel loaders offers significant fuel savings and lower long-term costs. They meet emissions standards and are designed to improve fuel economy without compromising performance. Reliability, durability, and versatility make them the perfect machine to meet your needs. Rated load/capacity: 4t/2.5m3. Deutz/Cummins engine, electronic control, YD13 gearbox, joystick control, A/C, heavy-duty chassis, general-purpose bucket, luxury cab.
|
Wheel loader general specification |
MC945 |
|
rated load(kg) |
4000 |
|
bucket capacity(m3) |
2.35 |
|
lifting time(s) |
≤5.5 |
|
lifting,tiping,and down time(s) |
10.5 |
|
max. pulling force(kN) |
100 |
|
max. break force(kN) |
≧120 |
|
max.climbing grade(°) |
30 |
|
centrol of tyres(mm) |
6032 |
|
out side of bucket(mm) |
6328 |
|
lendth(mm) |
7670 |
|
width(mm) |
2680 |
|
height(mm) |
3375 |
|
wheel base(mm) |
3067 |
|
wheel track(mm) |
1860 |
|
Min.distance to the ground(mm) |
460 |
|
dumping height(mm) |
3000/3800 |
|
dumping distance at the highest position(mm) |
1100/1600 |
|
front speed range(km/h) |
0-36 |
|
rear speed range(km/h) |
0-22 |
|
operation weight(kg) |
12600 |
|
Engine information |
|
|
Manufacture/brand |
Dongfeng Cummins |
|
model |
6BT5.9-C180 |
|
cylinder number |
6-102×120 |
|
rated power(kW) |
132 |
|
Max torque/speed(N·m/r/min) |
750/1300-1400 |
|
Transmission system information |
|
|
torque convertor model |
WG180 |
|
type |
electrical control fixed shaft power shift |
|
gear shifting |
F4R3 |
|
axle model |
GZH420 |
|
tyres model |
20.5-25 |
|
Working control system information |
|
|
working control type |
joysticks control |
|
Oil information |
|
|
fuel tank volume(L) |
150L |
|
hydraulic oil volume(L) |
150L |
|
radiator liquid volume(L) |
30L |
|
engine oil volume(L) |
13L |
|
transmission oil volume(L) |
45L |
