Maximum digging height: 9670MM
Bucket capacity: 1.1m³
Rated power/speed: Cummins National II engine 133KW/2000rpm
Equipped with Cummins engine which has strong power. Equipped Kawasaki hydraulic components,the operation is accurate. Adopted side deceleration bridge heavy wheels (special for construction machinery) . The loading unloading capacity is stronger,and suitable for multiple work environments. Equipped cold and warm air conditioning. Steering wheel that can be adjusted. Levitation seats. Large color screen. The design of the buttons is reasonable. Luxury cabin. Design of front-shovel and rear-leg.The structural parts are strengthened. Adapt to all types of complex work.
Main configuration:
Cummins National II engine 133 kW, Kawasaki main pump, Parker valve, with outriggers, bulldozer, crushing pipeline, and heating and cooling air conditioning.
|
Maximum digging height: mm |
9670 |
|
Maximum unloading height: mm |
6817 |
|
Maximum digging depth: mm |
6559 |
|
Maximum digging radius: mm |
9897 |
|
Maximum surface excavation radius: mm |
9697 |
|
Minimum turning radius of front end: mm |
3636 |
|
Minimum turning radius at rear end: mm |
2855 |
|
Overall dimensions (length × width × height): mm |
9524×2710×3111 (3365cm to the top of the boom) |
|
Wheelbase: mm |
1900 |
|
Axlebase: mm |
2850 |
|
Bucket capacity: m³ |
1.1 |
|
Rotation speed: r/min |
11.5 |
|
Low gear travel speed: km/h |
8 |
|
High speed travel: km/h |
30 |
|
Gradeability |
30° |
|
Maximum digging force of bucket arm: KN |
104KN |
|
Maximum bucket digging force: KN |
148KN |
|
Machine weight: kg |
22300kg |
|
System flow: L/min |
2×224 |
|
Rated pressure: MPa |
33 |
|
Rated power/speed |
Cummins National II engine 133KW/2000rpm |
|
Minimum ground clearance: mm |
260 |
|
Counterweight ground clearance: mm |
1250 |
|
Boom: mm |
5700 |
|
Arm: mm |
2900 |
|
Main pump |
Kawasaki |
|
Main valve |
Parker |
|
bridge |
Fuanda |
|
Travel motor |
Hytek |
|
Gearbox |
ZF |
