Swing Speed : 0-11rmp
Bucket Capacity : 3m³
Power/revolution speed : 298KW/2000rmp
1、Equipped with a domestic famous brand engine and advanced turbocharging technology, ensuring strong power, high-altitude adaptability, lower fuel consumption, and reduced emissions. New cooling fans and large mufflers minimize machine noise.
2、High-end hydraulic configuration includes double pump confluence, full hydraulic pilot, 360-degree rotation, and imported components. Features oil cylinder buffer functions, double pump confluence technology for enhanced operation speed, and improved vibration absorption for precise control.
3、Improved design elements such as the caterpillar frame, forged bucket rod hinge, whole-arm welding, and wear-resistant steel plates enhance overall durability and service life.
4、Expanded visibility with larger windows and skylight glass, ergonomic controls, luxury cab with LCD panel and seat, and air conditioning for comfort and efficiency.
5、Electric throttle control, automatic idling function, multi-function LCD monitor, and GPS satellite positioning system for remote diagnostics, maintenance reminders, and efficient operation.
6、Ground-level filters and oil-water separator for easy access, large capacity fuel tank, super large toolbox, and longer maintenance cycles due to high-quality components.
| Specifications | |
| Bucket Capacity(m3) | 3 |
| Swing Speed(rmp) | 0-11 |
| Gradeablity(°) | 35 |
| Max.Bucket Digging Force(KN) | 325 |
| Max.Arm Digging Force(KN) | 253 |
| Engine Model | OSM11 |
| Power/revolution speed(KW/rmp) | 298/2000 |
| Tire Model | — |
| System Pressure(MPa) | 35 |
| Machine size | |
| Dimension Length*Width*Height(mm) | 11690x3360x3810 |
| Cabin Height(mm) | 3309 |
| Axle Base(mm) | 4621 |
| Wheel(track) Distance(mm) | 2760 |
| Minimum ground clearance(mm) | 602 |
| Tail Swing Radius(mm) | 3760 |
| Working range | |
| Max.Digging Height(mm) | 11142 |
| Max.Dumping Height(mm) | 7779 |
| Max.Digging Depth(mm) | 5756 |
| Max.Vertical Digging Depth(mm) | 5064 |
| Max.Digging Radius(mm) | 10726 |
| Min.Swing Radius(mm) | 4390 |
