Rated Power: 92kW
Rated Capacity: 1.6m³
Operating Weight: 8000kg
|
Rated capacity |
1.6m³ |
|
Rated weight |
2800kg |
|
Operating weight |
8000kg |
|
Performance of bucket being set level |
Yes |
|
Max. breakout force |
70KN |
|
Max. drawbar pull |
45KN |
|
Max. grade ability |
38° |
|
Total of three time:lifting dumping lowering |
9.7m |
|
Max.dump height |
3.2m/3.5m |
|
Max.dump reach |
1084mm |
|
Min. ground clearance |
310mm |
|
Wheel base |
2470mm |
|
Tread |
1380mm |
|
Overall dimensions (length*width*height) |
7100*2400*3100mm |
|
Engine |
WEICHAI/ CUMMINS |
|
Model |
WEICHAI WP6G125E22/ CUMMINS 6BT5.9-C125/ |
|
Pattern |
inline,water cooled,dir.inject,fourstrokees |
|
Number of cylinders- internal diameter*strokes |
4-108*120 |
|
Max.torsion |
261Nm |
|
Rated power |
92KW |
|
Min.fuel consuming rate |
216g/kw.h |
|
Specified rotational speed |
2400r/min |
|
Transmission |
Gearbox seperated from torque converter |
|
Model of torque device |
YJ280 |
|
Pattern |
3-element,single stage |
|
Pattern of gearboxes |
FULL-powershift,countersaft type |
|
Number of great shift |
4forward,4reverse |
|
Max.travel speed |
30km/h |
|
Main reducer type |
arc taper gear moderation of first grade |
|
Pattern of wheelside moderation |
planet gear moderation of single |
|
Type size |
17.5-25 |
|
Front type pressure |
220KPa |
|
Rear type pressure |
180KPa |
|
Steering angle(each direction) |
35°±1 |
|
Min.turning radius(outside of bucket |
4500mm |
|
Parking brake |
Soft axle control,outside bunch drum type |
|
Fuel capacity |
80L |
|
Pressure of working hydraulic system |
160kgf/cm 2 |
