RATED POWER: 92kW/2300rpm
BUCKET CAPACITY: 2.0 m³
lifting time: 5.5S
*Weichai DEUTZ diesel engine, higher power and reliability.
*Hydrodynamic transmission, three-element and single stage torque converter, high reliability, easy maintenance.
*Hangzhou Advance Gearbox Group BS428 powershift transmission, high efficiency and easy maintenance.
*Gear-shift controlled by flexible shaft makes operation more flexible and reliable.
*Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoids oil leakage obviously;
* Air over hydraulic disks on four wheel brakes.
*Large space articulated frame makes operation and traveling stable.
*Working device with automatically leveling ability at high position.
*Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
*Integral, luxury instrument board.
*New, luxury cabin.
|
Item |
Specifications |
Item |
Specifications |
|
Bucket capacity |
2.0 m3 |
Min. turning radius (outside of rear wheels) |
5160mm |
|
Rated load |
3000 kg |
Steering angle |
36º |
|
Dumping height |
3000 mm |
Min. ground clearance |
375mm |
|
Dumping distance |
1100 mm |
Wheel base |
2845mm |
|
Boom lifting time |
5.5 S |
Tread |
1800mm |
|
Total cycling time |
10 S |
Engine model |
WP6G125E23 |
|
Max. speed |
36 km/h |
Rated power |
92kW/2300rpm |
|
Max. breakout Force |
120 kN |
Tyre specifications |
17.5-25 |
|
Max.drawing force |
90 kN |
Overall dimensions |
7020*2510*3300mm |
|
Max. Gradeability |
30° |
Operating weight |
10600kg |
